Cylinder Accessory

Cylinder Accessory

  • Product parameters
  • Product size

SI Series Standard Cylinder Accessory (IS015552 Standard)

LB Foot Overall Dimension

Dimension

Bore/Symbol 32  40  50  63  80  100  125
AA 32  36  45  50  63  71  90
AB 30  35  40  45  45  55  60
AC 32  36  45  50  63  75  90
AD 32.5  38  46.5  56.5  72  89  110
AE 45  52  65  75  95  115  140
AF 24  28  32  32  41  41  45
AG 11  8  15  13  14  16  18
AH 15.8  17  21.8  21.8  27  26.5  35
AI 4  4  5  5  6  6  7
AJ 142  161  170  186  208  219  250
AK 7  7  9  9  11  11  12.5
AL 7  10  10  10  12  14.5  16.5

FA / FB Flange Overall Dimension

Dimension

Bore/Symbol 32  40  50  63  80  100  125
BA 30.3  35.3  40.3  45.3  45.3  55.3  60.3
BB 10  10  12  12  16  16  20
BC 45  52  65  76  94  112  140
BD 32  36  45  50  63  75  90
BE 80  90  110  120  150  175  224
BF 64  72  90  100  126  150  180
BH 6.5  6.5  8.5  8.5  10.5  10.5  15
AJ 10.5  10.5  13.5  13.5  16.5  16.5  19
AK 6.5  6.5  8.5  8.5  10.5  10.5  12.5
BP 7  9  9  9  12  14  16
T 32.5  38  46.5  56.5  72  89  110

CA Hinge Overall Dimension

Dimension

Bore/Symbol 32 40 50 63 80 100 125
S 45 52 65 76 94 112 140
T 32.5 38 46.5 56.5 72 89 110
RR 6.5 6.5 9 9.5 11 11.5 12
DB 34 41 54 65 83 101 123
DC 22 25 27 32 36 41 50
DD 10 11 13 16 16 20 25
DE 10 12 12 16 16 20 25
DQ 26 28 32 40 50 60 70
D 6.5 6.5 8.5 8.5 10.5 10.5 12.5
E 14 17 17 22 24 25 30



CB Hinge Overall Dimension

Dimension

Bore/Symbol 32 40 50 63 80 100 125
S 45 52 65 76 94 112 140
T 32.5 38 46.5 56.5 72 89 110
D 6.5 6.5 8.5 8.5 10.5 10.5 12.5
E 14 17 17 22 24 25 30
RR 6.5 6.5 9 9.5 11 11.5 12
CB 34 41 54 65 83 101 123
CC 22 25 27 32 36 41 50
CD 10 11 13 16 46 20 25
CE 10 12 12 16 16 20 25
CP 26 28 32 40 50 60 70
CT 45 52 60 70 90 110 120
PA1 53 60 68 78 100 120 130
PB1 46.5 53.5 61.5 71.5 91.5 111.5 121.5



YB Hinge Overall Dimension

Dimension

Bore/Symbol 32  40  50  63  80  100
AH 32  36  45  50  63  71
H 8  10  12  12  14  15
CD 10  12  12  16  16  20
G1 31  35  45  50  60  70
G2 18  22  30  35  40  50
G3 21  24  33  37  47  55
CB 26  28  32  40  50  60
K1 38  41  50  52  66  76
K2 51  54  65  67  86  96
S2 6.6  6.6  9  9  11  11
R 10  11  13  15  15  19

SC/SU Series Standard Cylinder & SQ Series Large Size Cylinder Accessory
LB Foot Overall Dimension

Dimension

Bore/Symbol

32

40

50

63

80

100

 125

160

200

AA

153

169

173

184

200

210

249

328

380

AC

134

140

149

158

168

174

249

288

320

AD

9.5

14.5

12

12

16

18

18

20

28

AE

50

57

68

80

97

112

140

180

220

AF

33

36

47

56

70

84

90

115

135

AG

20.5

23.5

28

31

30

30

45

60

70

AJ

28

30

36.5

41

49

57

90

115

135

AP

9

12

12

12

14

14

16

18

22

AT

3

3

3

3

4

4

7

7

9



FA / FB Flange Overall Dimension

Dimension

Bore/Symbol

32

40

50

63

80

100

125

160

200

BA

28.3

32.3

38.3

38.3

47.3

47.3

62

72

82

BB

10

10

10

12

16

16

20

20

25

BC

47

52

65

76

95

115

141

180

220

BD

33

36

47

56

70

84

90

115

135

BE

72

84

104

116

143

162

218

278

322

BF

58

70

86

98

119

138

180

230

270

BH

6.5

6.5

6.5

8.5

10.5

10.5

13

15

18

AJ

10.5

10.5

10.5

13.5

16.6

16.6

19

25

25

AK

6.5

6.5

6.5

8.5

10.5

10.5

12.5

18

18

BP

7

7

9

9

12

12

16

18

22

T

33

37

47

56

70

84

110

140

175



CA Clevis Overall Dimension

Dimension

Bore/Symbol

32

40

50

63

80

100

125

160

200

S

45

50

62

75

94

112

140

177

217

T

33

37

47

56

70

84

110

140

175

DC

34

34

34

34

48

48

50

55

60

DD

14

14

15

15

20

20

25

30

30

DE

12

14

14

14

20

20

25

30

30

DJ

14

14

15

15

20

20

25

28

25

DQ

16

20

20

20

32

32

70

90

90

D

6.5

6.5

6.5

8.5

10.5

10.5

12.5

18

18



CB Double Earring Overall Dimension

Dimension

Bore/Symbol

32

40

50

63

80

100

125

160

200

CC

19

19

19

19

32

32

50

55

60

CD

5

5

3

3

8

8

25

30

35

CE

12

14

14

14

20

20

25

30

30

CJ

13

13

15

15

21

21

25

25

33

CP

16.3

20.5

20.3

20.3

32.3

32.3

70

90

90

CT

32

44

52

52

64

64

120

162

75

PAI

41

53

61

61

75

75

136

176

188

PBI

34

46

54

54

66

66

124

162

177

S

48

50

62

75

94

112

140

176

217

T

33

37

47

56

70

84

110

140

175

D

6.5

6.5

6.5

8.5

10.5

10.5

12.5

18

18

TC Center Trunnion Overall Dimension

Dimension

Bore/Symbol

32

40

50

63

80

100

125

160

200

EB

87

113

126

138

164

182

210

276

320

EC

53

63

76

88

114

132

150

94

244

ED

33

37

47

56

70

84

110

140

175

EE

55

63

76

88

114

132

160

200

245

EG

16

25

25

25

25

25

25

36

36

EP

16

25

25

25

25

25

30

32

32

ET

30

30

30

30

35

40

36

40

46

S

37.5

45.5

55.5

68.5

87.5

107.5

135

72

210



Y/I Knuckle Overall Dimension

Dimension

Model

NA

NB

NC

ND

NE

NF

NG

NH

NJ

NK

MM

NP

NQ

PA

PB

F-M10125I/Y

19

20

10

40

52

15

20

M10xl.25

15.5

16

10

20

52

30

21

F-M12125I/Y

24

24

12

48

62

24

20

M12xl.25

20.5

20

12

24

62

36

27

F-M16150I/Y

32

32

16

64

89

32

23

M16xl.5

26

30

16

32

83

44

34

F-M16150I/Y

32

32

16

64

89

32

23

M16xl.5

26

30

16

32

83

44

34

F-M20150I/Y

40

40

20

80

112

40

30

M20xl.5

30

38

20

39.5

105

52

42

F-M20150I/Y

40

40

20

80

112

40

30

M20xl.5

30

38

20

39.5

105

52

42

F-M27200I/Y

62

49

20

99

122

54

50

M27x2

28

38

30

43

120

75

66

F-M36200I/Y

70

61

30

125

155

43

70

M36x2

40

53

40

43

153

96

82

F-M36200I/Y

70

61

30

125

155

43

70

M36x2

40

53

40

43

153

96

82

CK Type Y Knuckle Overall Dimension

Dimension

Model

KK

B

CE

CM

CR

CW

D1

G

LE

F-M04070CK

M4X0.7

8

16

4

21

4

8

11

8

F-M05080CK

M5X0.8

10

20

5

26

5

9

13

10

F-M06100CK

M6x1

12

24

6

31

6

10

16

12

F-M08125CK

M8x1.25

16

32

8

42

8

14

20

16

F-M10125CK

M10x1.25

20

40

10

52

10

18

25.5

20

F-M12125CK

M12x1.25

24

48

12

62

12

20

29.5

24

F-M14150CK

M14x1.5

27

56

14

72

14

24

29.5

28

F-M16150CK

M16x1.5

32

64

16

83

16

26

38.5

32

F-M18150CK

M18x1.5

36

72

18

94

18

30

42

36

F-M20150CK

M20x1.5

40

80

20

105

20

34

47

40

F-M27200CK

M27x2

55

112

30

148

30

48

63

56



PHSA Universal Piston Rod Eye Overall Dimension

Dimension

Model

D3

D

D2

D5

S

B

L5

C1

H1

L3

D4

L4

A°

F-M05070PHSA

M5X0.8

5

18

11

9

8

4

6

27

10

8.5

36

13

F-M06100PHSA

M6X1

6

20

13

11

9

5

6.75

30

12

10

40

13

F-M08125PHSA

M8X1.25

8

24

16

14

12

5

9

36

16

12.5

48

14

F-M10125PHSA

M10X1.25

10

28

19

17

14

6.5

10.5

43

20

15

57

13

F-M12125PHSA

M12X1.25

12

32

22

19

16

6.5

12

50

22

17.5

66

13

F-M14125PHSA

M14X1.5

14

36

25

22

19

8

13.5

57

25

20

75

16

F-M16125PHSA

M16X1.5

16

40

27

24

21

8

15

64

28

22

84

15

F-M18150PHSA

M18X1.5

18

44

31

27

23

10

16.5

71

32

25

93

15

F-M20150PHSA

M20X1.5

20

50

34

30

25

10

18

77

33

27.5

102

14

F-M27200PHSA

M27X2

30

70

50

41

37

15

25

110

51

40

145

17



FDJT Piston Floating Jiont Overall Dimension

Dimension

Model

MI

MJ

MA

MB

MD

ME

MF

MH

MP

MC

MO

MG

F-M06100FDJT

M6X1

M6X1

35

13

12

16

8

6

10

5

10

5

F-M08125FDJT

M8X1.25

M8X1.25

53

20

18

24

12

8

13

6

14

6

F-M10125FDJT

M10X1.25

M10X1.25

58

22

21

26

13

10

17

7

17

6

F-M12125FDJT

M12X1.25

M12X1.25

64

22

24

32

15

12

19

8

19

7

F-M16150FDJT

M16X1.5

M16X1.5

90

27

36

45

23

17

27

12

24

8

F-M20150FDJT

M20X1.5

M20X1.5

102

32

40

53

28

22

32

13

30

10

F-M27200FDJT

M27X2

M27X2

120

37

48

60

35

26

41

15

36

12

DN /DSN Mini Cylinder Accessory

FA Overall Dimension

Dimension

Symbol

 B C
(DN、DSN Series)		 C(DS/DT Series) BB BC BD BE BF BP F
Bore Stroke 0-50 50-100 100-150
8 28 46 71  - - 3  22  - 40  30  4.5  12
10 28 46 71  - - 3  22  - 40  30  4.5  12
12 38 50 75  - - 4  30  - 52  40  5.5  17
16 37 55 80  105  - 4  30  - 52  40  5.5  16
20 43 64 89  114  139  5  40  - 66  50  6.6 16
25 50 66 91  116  141  5  40  - 66  50  6.6  22
32 48 72 97  122  147  5  45  20  80  60  7  18
40 51 72 97  122  147  5  50  30  100  80  9   20

LB Overall Dimension

Dimension

Symbol

B

AA(DN、DSN Series)

AA (DS/DT Series)

AB

AC(DN、DSN Series)

AC (DS/DT Series)

AD

AE

AF

AH

AL

AP

AQ

AT

F

Bore Stroke

0-50

50-100

100-150

0-50

50-100

100-150

8

28

78

103

-

-

-

68

93

-

-

-

35

25

16

11

4.5

5

3

12

10

28

78

103

-

-

-

68

93

-

-

-

35

25

16

11

4.5

5

3

12

12

38

90

115

-

-

-

78

103

-

-

-

42

32

20

14

5.5

6

4

17

16

37

95

120

145

-

-

83

108

133

-

-

42

32

20

14

5.5

6

4

16

20

43

114

139

164

189

-

98

123

148

173

-

54

40

25

17

6.6

8

5

16

25

50

116

141

166

191

-

100

125

150

175

-

54

40

25

17

6.6

8

5

22

32

48

118

143

168

193

49

104

129

154

179

28

66

52

28

16

7

7

5

18

40

51

132

157

182

207

58

112

137

162

187

30

80

60

33

20

9

10

5

20



SDB Overall Dimension

Dimension

Symbol

D

Q

CA

CB(MAL Series)

CB(MSAL/MTAL Series)

CD

CF

CH

CT

CP

CQ

Bore Stroke

0-50

50-100

100-150

8

11.3

8.1

17.3

76

101

-

-

20

12.5

24

2.5

4.5

13.1

10

11.3

8.1

17.3

76

101

-

-

20

12.5

24

2.5

4.5

13.1

12

13

12.1

23.3

91

116

-

-

25

15

27

3

5.5

18.1

16

13

12.1

23.3

98

123

148

-

25

15

27

3

5.5

18.1

20

16

16.1

30

115

140

165

190

32

20

30

4

6.5

24.1

25

16

16.1

30

126

151

176

201

32

20

30

4

6.5

24.1

32

19.5

20.1

34.6

135

160

185

210

41

24

35

4

9

28.1

40

26

20.1

36.6

138

163

188

213

52

30

40

5

9

30.1



I Knuckle Overall Dimension

Dimension



Model

NB

NC

ND

NE

NF

NG

NH

NM

Bore

8

10

12

16

20

25

32

40

F-M04070I

10

4

16

21

7

6

M4x0.7

4

Adapted fitting form

√

√













F-M06100I

12

5

21

28

8.5

8

M6x1

6





√

√









F-M08125I

16

8

30

40

11

15

M8x1.25

8









√







F-M10125I

20

10

40

52

15

18

M10x1.25

10











√

√



F-M12125I

24

12

48

62

24

18

M12x1.25

12

















F-M14150I

28

14

56

72

28

21

M14x1.5

14















√

CK Knuckle Overall Dimension

Dimension

Model

KK

B

CE

CM

CR

CW

D1

G

LE



F-M04070CK

M4X0.7

8

16

4

21

4

8

11

8

DSN8、DSN10

F-M06100CK

M6x1

12

24

6

31

6

10

16

12

DSN12、DSN16

F-M08125CK

M8x1.25

16

32

8

42

8

14

20

16

DSN20

F-M10125CK

M10x1.25

20

40

10

52

10

18

25.5

20

DSN25、 DSN32

F-M12125CK

M12x1.25

24

48

12

62

12

20

29.5

24



F-M14150CK

M14x1.5

27

56

14

72

14

24

29.5

28

DSN40

F-M16150CK

M16x1.5

32

64

16

83

16

26

38.5

32



F-M20150CK

M20x1.5

40

80

20

105

20

34

47

40





MA/MAC Mini Cylinder Accessory

FA Overall Dimension

Dimension

Symbol

B

C(MA Series)

C(MSA/MTA Series)

BB

BC

BD

BE

BF

BP

F

Bore/Stroke

0-50

50-100

100-150

16

38

60

85

110



3

26



52

40

5.5

16

20

40

76

101

126

151

4

38

-

64

50

6.5

12

25

44

76

101

126

151

4

38

-

64

50

6.5

14

32

44

76

101

126

151

4

47

33

72

58

6.5

14

40

46

77

102

127

152

4

50

36

84

70

6.5

14

LB Overall Dimension

Dimension

Symbol

B

AA(MA Series)

AA(MSA/MTA Series)

AB

AC (MAL Series)

AC(MSAL/MTAL Series)

AE

AF

AH

AL

AP

AQ

AT

F

Bore/Stroke

0-50

50-100

100-150

0-50

50-100

100-150

16

38

98

123

148

-

25

86

111

136

-

44

32

20

13

5.5

6

3

16

20

40

122

147

172

197

25

106

131

156

181

54

40

25

15

6.5

8

3

12

25

44

122

147

172

197

29

106

131

156

181

54

40

25

15

6.5

8

3

14

32

44

142

167

192

217

19

126

151

176

201

59

45

32

25

6.5

8

4

14

40

46

143

168

193

218

21

127

152

177

202

64

50

36

25

6.5

8

4

14



SDB Overall Dimension

Dimension

Symbol

D

S

Q

CA

CB(Series)

CB (MSA/MTA Series)

CD

CE

CF

CH

CT

CP

CQ

Bore/Stroke

0-50

50-100

100-150

16

16

9

12

-

107

132

157

-

23

-

12

20

2

5.5

16

20

21

12

16

51

128

153

178

203

48

67

32

32

3

6.5

22

25

21

12

16

51

132

157

182

207

48

67

32

32

3

6.5

22

32

27

15

16

51

135

160

185

210

52

67

36

36

4

6.5

24

40

27

15

20

55

138

163

188

213

56

71

40

40

4

6.5

28



I Knuckle Overall Dimension

Dimension

Model

NB

NC

ND

NE

NF

NG

NH

NM

Bore

16

20

25

32

40

F-M04070I

10

4

16

21

7

6

M4x0.7

4

Adapted fitting form











F-M06100I

12

5

21

28

8.5

8

M6x1

6

√









F-M08125I

16

8

30

40

11

15

M8x1.25

8



√







F-M10125I

20

10

40

50

15

18

M10x1.25

10





√

√



F-M12125I

24

12

48

62

24

18

M12x1.25

12









√

MAL/MALC Mini Cylinder Accessory

FA Overall Dimension

Dimension

Symbol B C(MAL  Series) C (MSAL/MTAL Series) BB BC BD BE BF BP F
Bore/Stroke  0-50 50-100 100-150
16  38  52  77  102  - 3  26  - 52  40  5.5 14
20  40  70  95  120  145  4  38  - 64  50  6.5 12
25  44  70  95  120  145  4 38  - 64  50  6.5 14
32  44  70  95  120  145  4 47  33  72  58  6.5 14
40  46  92  117  142  167  4  50  36  84  70  6.5 14

LB Overall Dimension

Dimension

Symbol

B

AA(MAL Series)

AA(MSAL/MTAL Series)

AB

AC(MAL Series)

AC(MSAL/MTAL Series)

AE

AF

AH

AL

AP

AQ

AT

F

Bore/Stroke

0-50

50-100

100-150

0-50

50-100

100-150

16

38

90

115

140

-

25

78

103

128

-

44

32

20

13

5.5

6

3

14

20

40

116

141

166

191

25

100

125

150

175

54

40

25

15

6.5

8

3

12

25

44

116

141

166

191

29

100

125

150

175

54

40

25

15

6.5

8

3

14

32

44

136

161

186

211

19

120

145

170

195

59

45

32

25

6.5

8

4

14

40

46

158

183

208

233

21

142

167

192

217

64

50

36

25

6.5

8

4

14

SDB Overall Dimension

Dimension

Symbol D S Q CA CB(MAL Series) CB(MSAL/MTAL Series) CD CE CF CH CT CP CQ
Bore/Stroke 0-50 50-100 100-150
16  16  9  12  - 96  121  146  - 23  - 12  20  2  5.5  16
20  21  12  16  51  122  147  172  197  48  67  32  32  3  6.5  22
25  21  12  16  51  126  151  176  201  48  67  32  32  3  6.5  22
32  27  15  16  51  129  154  179  204  52  67  36  36  4  6.5  24
40  27  15  20  55  153  178  203  228  56  71  40  40  4 6.5  28



I Knuckle Overall Dimension

Dimension

Model

NB

NC

ND

NE

NF

NG

NH

NM

Bore

16

20

25

32

40

F-M04070I

10

4

16

21

7

6

M4x0.7

4

Adapted fitting form











F-M06100I

12

5

21

28

8.5

8

M6x1

6

√









F-M08125I

16

8

30

40

11

15

M8x1.25

8



√







F-M10125I

20

10

40

52

15

18

M10x1.25

10





√

√



F-M12125I

24

12

48

62

24

18

M12x1.25

12









√
